| MODEL | 额定电压 | 使用电压 | 振子规格 | 额定转速 | 额定电流 | 堵转电流 | 端子阻抗 | 起动电压 |
| V | V | RPM | 嘛 | 嘛 | Ω | V | ||
| HS-408-Z13060110 | 1.3 | 1.0-1.6 | R1.9 * 3.0 | 11000±2000 | 60 | 90 | 13.8 | 0.9max |
| HS-408-Z30070100 | 3 | 2.0-3.5 | R2.5 * 2.8 | 10000±2000 | 70 | 90 | 31.5 | 1.1max |
| HS-408-Z30065130 | 3 | 2.0-3.5 | R2.2 * 2.0 | 13000±2000 | 65 | 90 | 31.5 | 1.1max |
| HS-410-Z13080125 | 1.3 | 1.0-1.6 | R1.9-3.0 | 12500±2000 | 80 | 120 | 11.4 | 0.9max |
| HS-412-Z30050090 | 3 | 2.0-3.5 | R2.0 * 5.0 | 9000±2000 | 70 | 80 | 30 | 1.1max |
| MODEL | 额定电压 | 使用电压 | 振子规格 | 额定转速 | 额定电流 | 堵转电流 | 端子阻抗 | 起动电压 |
| V | V | RPM | 嘛 | 嘛 | Ω | V | ||
| HS-408-Z13060110 | 1.3 | 1.0-1.6 | R1.9 * 3.0 | 11000±2000 | 60 | 90 | 13.8 | 0.9max |
| HS-408-Z30070100 | 3 | 2.0-3.5 | R2.5 * 2.8 | 10000±2000 | 70 | 90 | 31.5 | 1.1max |
| HS-408-Z30065130 | 3 | 2.0-3.5 | R2.2 * 2.0 | 13000±2000 | 65 | 90 | 31.5 | 1.1max |
| HS-410-Z13080125 | 1.3 | 1.0-1.6 | R1.9-3.0 | 12500±2000 | 80 | 120 | 11.4 | 0.9max |
| HS-412-Z30050090 | 3 | 2.0-3.5 | R2.0 * 5.0 | 9000±2000 | 70 | 80 | 30 | 1.1max |
